FEATURES
• High rigidity double clamping system to support high-feed machining
• Up to .024” (.6mm) total axial adjustment to ensure an excellent surface finish
• Multiple cutting edge geome- tries to cover any application, including 90°/75° lead angles
• 1.5” (40mm) available in cylindrical shank
• 2.0-5.0” (50mm-125mm) range in shell mill or monoblock bodies
• DOC capability of .157” (4mm) • Ability to re-tip cartridges
During CNC machining the cycle time is very important. To improve the productivity, while maintaining a perfect surface finish, IT.TE.DI. is now introducing the TEDI SFEED line with a higher number of cutting edges.
The fundamental characteristic is the high performance, which is due to the high rigidity and stability of the mill and of its components. So, to have those aspects with the high number of cutting edges, we developed a specially designed cutting edge cartridge.
When the screw is clamped, it pushes the cartridge towards the mill’s body; once the conical wedge has also been placed in its seat and it has been clamped, it further pushes the cartridge, thus locking it into place and proving better stability.
The precise height is guaranteed from the regulation of the adjusting wedge, that is placed below the cartridges. This product line also offers different cutting edge geometries to satisfy the customers requirements.
