90o MODULAR END MILLS
Part Number
1TJ1D-07015X6R01 1TJ1D-10015X7R01 1TJ1D-12017X8R01 1TJ1D-15017X8R01
DC LF
Cutting Functional Dia. Length
ZEFF
Eff. Teeth
Part Number
1TJ1D-06008TRR01 1TJ1D-07010TSR01 1TJ1D-10012TUR01
DC LF
Cutting Protruding Dia. Length
ZEFF
Eff. Teeth
WEP - See insert drawing for wiper options.
CCMS DHUB
Connection Hub Code Dia.
06 SERIES 1TJ1D (TOP•ON STYLE)
FORMERLY
Shoulder
DC
Channel
Ramp
LF
Corkscrew
Facing
Pocketing
CCMS DHUB
Coolant
WEP
.24APMX
0.750 1.50 3 M10 0.69 1.000 1.50 4 M12 0.81 1.250 1.75 5 M16 1.13 1.500 1.75 6 M16 1.13
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02"). Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
06 SERIES 1TJ1D (CHIP•SURFER STYLE) 90o MODULAR END MILLS (6MM INSERT)
FORMERLY
Shoulder
DC WEP
Channel Ramp
Corkscrew
Facing
Pocketing
Coolant
0.625 0.80 2 T10 0.61 0.750 1.00 3 T12 0.73 1.000 1.25 4 T15 0.95
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02"). Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
