Page 61 - CAT-027-6 IT.TE.DI. Catalog

CUTTER HOLDERS - METRIC
HOLDER BT A/B MAS 403
H1
H2
G1
D3
G2
G
ITEM NUMBER
API430AA16050
API430BA22050
API430AA22050
API430AA27060
API430AA32060
API440AC16050
API440AC16100
API440BC22050
API440AC22050
API440BC22100
API440AC22100
API440AC27060
API440AC27100
API440AC32060
API440AC32100
API440AC40060
API440AC40100
API440CC40060
API450BC22060
API450AC22060
API450BC22120
API450AC22120
API450AC27060
API450AC27120
API450AC32070
API450AC32120
API450AC40070
API450AC40120
API450CC40070
API450CC60070
BT HOLDER d2 TAPER DIMENSION SHAPE
30 A 16
30 B 22
30 A 22
30 A 27
30 A 32
40 A 16
40 A 16
40 B 22
40 A 22
40 B 22
40 A 22
40 A 27
40 A 27
40 A 32
40 A 32
40 A 40
40 A 40
40 C 40
50 B 22
50 A 22
50 B 22
50 A 22
50 A 27
50 A 27
50 A 32
50 A 32
50 A 40
50 A 40
50 C 40
50 C 60
H1 D1
50 41
50 50
50 50
60 68
60 88
50 41
100 41
50 58
50 50
100 58
100 50
60 68
100 68
60 88
100 88
60 98
100 98
60 98
60 58
60 50
120 58
120 50
60 68
120 68
70 88
120 88
70 98
120 98
70 98
D3
–
–
–
–
–
H2 G1 G2
13 – M6
19 – M10
19 – M10
21 – M12
24 – M16
13 M6
13 M6
19 M10
19 M10
19 M10
19 M10
21 M12
21 M12
24 M16
24 M16
27 M20
27 M20
27 M12
19 M10
19 M10
19 M10
19 M10
21 M12
21 M12
24 M16
24 M16
27 M20
27 M20
27 M12
40 M16
ADAPTORS
d2 D1
66.7
70 140
101.6
66.7
NOTE: Both metric and inch size cutters will fit on metric pilot adapters.
