Page 22 - CAT-027-6 IT.TE.DI. Catalog

PCD / CBN
MONOBLOCK TYPE CUTTERS - METRIC
BT A/B MAS 403
PRODUCT CODE1
BT TAPER DIMENSION
D* ø nom.
D1
Z
L1
MATERIAL
WEIGHT (kg)3
TRGBC40D040-06-00 TRGBC40D063-10-00 TRGBC40D100-16-00
40 40 40 63 40 100
41,4 6 100
64,4 10 100 101,4 16 100
Steel 1,8 Steel 2,7 Steel 4,2
TRGBC40D050-08-00
40
50
51,4
8
100
Steel
2,1
TRGBC40D080-12-00
40
80
81,4
12
100
Steel
3,3
TRGBC40D125-20-00
40
125
126,4
20
100
Steel
5,6
PCD / CBN
MONOBLOCK TYPE CUTTERS - METRIC
ISO A/B DIN 69871
PRODUCT CODE1
ISO TAPER DIMENSION
D* ø nom.
D1
Z
L1
MATERIAL
WEIGHT (kg)3
TRGIC40D040-06-00 TRGIC40D063-10-00 TRGIC40D100-16-00
40 40 40 63 40 100
41,4 6 100
64,4 10 100 101,4 16 100
Steel 1,6 Steel 2,3 Steel 3,8
TRGIC40D050-08-00
40
50
51,4
8
100
Steel
2,0
TRGIC40D080-12-00
40
80
81,4
12
100
Steel
2,9
TRGIC40D125-20-00
40
125
126,4
20
100
Steel
5,2
*Minimum diameter guaranteed with standard inserts. Refer to related table of available cutting geometry for more detail. 1Item number refers to body only, without inserts.
3 The weight is referred to the assembled part (cutter body with cutting parts).
Monoblock cutters are non-stock standard - request a quote.
22
