PCD / CBN
INSERTS
Inserts are screw clamped in mill body to help assembling process. Several combination of insert are available to cover a wide range of material and applications.
A
CUTTING EDGE GRADE
PCD
PB*
CBN
CH*
R
P
INSERT TYPE
MILLING
WIPER
MILLING for 2 inch and smaller
CUTTING EDGE
M
SINGLE TIP
B
DOUBLE TIP
T
FULL EDGE
PRODUCT LINE
TRG
P
A
02
B
R
PB
CUTTING MATERIAL
P
PCD
C
CBN
ROTATION
R
RIGHT
L
LEFT
CUTTING EDGE GEOMETRY
01
91
D D1
02
92
D1=D+1,4
R D1=D+1,4
05 05
D1=D+1,4 R=.8MM
45
R D1=D+1,4
07
D D1
09
T
*Alternative grades available, please contact IT.TE.DI. for choosing the best grade.
