CBN SHELL CUTTERS - METRIC
TEDI MILL®
D
D1 (d.max) d2
ITEM d2 NUMBER
FTC050R040S 22 FTC063R060S 22 FTC080R080S 27 FTC080R100S 27 FTC100R080S 32 FTC100R120S 32 FTC125R100S 40 FTC125R140S 40 FTC125R160S 40 FTC160R140S 40 FTC160R180S 40 FTC200R160S 60
FTC200R240S 60
HOLDER D (*) SHAPE Ø NOM.
A 50 B 63 A 80 A 80 A 100 A 100 A 125 A 125 A 125 C 160 C 160 C 200 C 200
H1 (adj.)
D1
51,4 64,4 81,4 81,4 101,4 101,4 126,4 126,4 126,4 161,4 161,4 201,4 201,4
Z H1
4 50 6 50 8 50
10 50 8 50 12 50 10 63 14 63 16 63 14 63 18 63 16 63 24 63
MATERIAL
ROTATION
(*) Minimum diameter guaranteed with standard cartridges. Ref. page 31 depending on cartridge geometry. (1) Item number refers to body only, without cartridges.
Metric CBN cutter bodies are non-stock standard - request a quote.
